Linear roller guideways from SCHNEEBERGER always mean high quality. Our customers are leaders in semiconductors and electronics, automation and handling systems, metrology, optics and biotechnology or medicine. We cover a significant part of application areas with our wide range of standard linear roller guideways.
SCHNEEBERGER uses its high precision profiled linear guideways (rollers or ball monorail guideways) worldwide for a wide range of applications in mechanical engineering, from simple handling tasks to heavy machining processes.
All our guide rails are available in different sizes and performance classes. If you can't find what you’re looking for in the standard catalogue, we also offer customized solutions with tailor-made products.
INA full complement linear recirculating roller bearing and guideway assemblies are the heavy duty designs in the range of INA monorail guidance systems.
They are used wherever linear guidance systems must support extremely heavy loads, where particularly high rigidity is required and where very precise travel is also necessary.
These preloaded units for long, unlimited stroke lengths are particularly suitable for use in machine tools.
A guidance system comprises at least one carriage, one guideway, one dummy guideway, plastic closing plugs and one mounting set per carriage.
The guideways are made from hardened steel and are ground on all faces, the rolling element raceways are precision ground.
Location from above or below
Guideways TSX..-E (-ADB, -ADK) and TSX25-D (-ADB, -ADK) are located from above and have through holes with counterbores for the fixing screws. Guideways TSX..-E-U and TSX25-D-U are located from below and have threaded blind holes.
Slot for covering strip
Guideways TSX..-E-ADB and TSX25-D-ADB have a slot for the adhesive bonded steel covering strip ADB, while guideways TSX..-E-ADK and TSX25-D-ADK have a slot with undercut for the clip fit steel covering strip ADK.
Multi-piece guideways
If the required guideway length lmax is greater than the value in the dimension tables, the guideways are supplied in several segments.
The scope of delivery includes various accessory parts as standard.
The dummy guideway prevents damage to the rolling element set and prevents the rolling elements from falling out while the carriage is separated from the guideway.
Carriages are always pushed directly from the guideway onto the dummy guideway and must remain there until they are remounted.
Plastic closing plugs
The closing plugs close off the counterbores of the guideway holes flush with the surface of the guideway.
Optionally, two-piece plastic plugs and closing plugs made from brass or steel are also available.
