A HIWIN Technologies linear guide system typically consists of:
Rail (Guideway): Hardened steel track mounted on a machine base
Block (Carriage): Moves along the rail with rolling elements
Rolling Elements: Usually balls or rollers that reduce friction
End caps & seals: Keep lubrication in and contaminants out
⚙️ Key Features
High precision: Accurate positioning and repeatability
Low friction: Smooth motion using recirculating balls
High load capacity: Can support loads in multiple directions
Long service life: Durable with proper lubrication
Interchangeability: Blocks and rails can often be replaced independently
📊 Main Series of HIWIN Linear Guides
1. HG Series (Heavy Load)
High rigidity and load capacity
Suitable for CNC machines and heavy automation
2. EG Series (Low Profile)
Compact design
Ideal for space-constrained applications
3. MG Series (Miniature)
Small size for precision equipment
Used in electronics and medical devices
4. RG Series (Roller Type)
Uses rollers instead of balls
Higher load capacity and rigidity
🧩 Common Specifications
Rail widths: 15 mm to 65 mm (or more)
Accuracy grades: N (Normal), H (High), P (Precision), SP, UP
Preload options: Light, medium, heavy
Material: Hardened alloy steel
Lubrication: Grease or oil
📐 Applications
CNC machining centers
3D printers
Industrial automation
Robotics
Packaging machines
✅ Advantages
Smooth and quiet operation
High efficiency (less energy loss)
Easy installation and maintenance
Suitable for high-speed motion
